- Toate cablurile au un design modular. Instaleaza doar cablurile de care ai nevoie pentru a reduce aglomerarea, cu scopul de a mari fluxul de aer, ceea ce va imbunatati performanta termica a carcasei.
- Toate condensatoarele sunt japoneze, de inalta calitate, pentru a produce performante eficiente si pentru a asigura fiabilitatea mai lunga.
- Viteza ventilatorului se va regla in functie de sarcina sistemului. Si ventilatorul se va opri atunci cand sistemul este inactiv sau sub sarcina mica (sub 20% incarcare). Structura cu 2 bile de rulment asigura o durata de viata mai lunga.
| Standard | 80Plus-Gold |
|---|---|
| Connectivity | Yes |
| PFC | Active |
| PSU Power | 501W-750W |
| PSU Type | ATX |
| RGB | Nu |
| Number of fans | 1 fan(s) |
| EPS power connector (8-pin) | Yes |
| AC input voltage | 100 – 240 V |
| Mean time between failures (MTBF) | 100000 h |
| Power Factor Correction (PFC) type | Active |
| Floppy disk drive connector | Yes |
| Cabling type | Fully-Modular |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS Gold |
| Harmonized System (HS) code | 84733020 |
| On/off switch | Yes |
| AC input frequency | 47 – 63 Hz |
| Input current | 10 A |
| Max output current (+3.3V) | 20 A |
| Max output current (+5V) | 20 A |
| CPU power connector (4+4 pin) | Yes |
| Purpose | PC |
| Total power | 750 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 90% |
| Width | 150 mm |
| Depth | 160 mm |
| Motherboard power connector | 20+4 pin ATX |
| ATX power connector (20+4 pin) | Yes |
| Combined power (-12V) | 744 W |
| Max output current (-12V) | 62 A |
| Fan diameter | 13.5 cm |
| Power factor | 0.9 |
| Hold time | 16 ms |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Number of SATA power connectors | 6 |
| PCI Express connector | Yes |
| ATX version | 2.31 |
| Fan location | Top |
| Combined power (+3.3V) | 120 W |
| Peripheral (Molex) power connectors (4-pin) | 6 |
| Combined power (+5V) | 120 W |
| PCI Express power connectors (6+2 pin) | 6 |
| Power Good signal delay range | 100 – 150 ms |
| Motherboard power cable length | 65 cm |
| SATA power cable length | 450,550,650,750 mm |
| Floppy drive power connector | 2 |
| Height | 86 mm |
| Producator | GIGABYTE |
| Garantie | 120 |
